7kW 11kW 22kW Portable Electric Vehicles (EV) Charger of NACS Standard

The NACS Standard Portable EV Charging Station is a smart, reliable, and travel-friendly solution designed for Tesla drivers and other compatible electric vehicles.

With a compact and lightweight design, this portable charger is perfect for home charging, long road trips, or outdoor use. Whether you’re parked in your garage or powering up on the road, it offers the freedom and convenience EV owners expect from a modern charging solution.

Engineered for fast, stable charging and built to last, the unit includes advanced safety features to protect both the vehicle and user. Certified for quality and safety, it also boasts an IP65-rated enclosure, making it resistant to dust, water, and harsh weather—ideal for indoor or outdoor environments.

Send email to us Document Download

Product Detail

Product Tags

Feature

● Designed for Tesla (NACS): Compatible with Tesla and other EVs using the NACS interface.

● Compact & Portable: Lightweight and easy to carry, perfect for everyday or emergency use.

● Adjustable Current: Customize charging levels for various scenarios.

● Certified & Safe: Meets stringent safety standards for dependable use.

● IP65 Protection: Weather-resistant for indoor and outdoor applications.

● Real-Time Temperature Monitoring: Ensures efficient and safe charging at all times.

Specification of Portable EV Charger

Model	EVSEP-7-NACS	EVSEP-9-NACS	EVSEP-11-NACS
Electrical Specifications
Operating Voltage	90-265Vac	90-265Vac	90-265Vac
Rated Input/ Output Voltage	90-265Vac	90-265Vac	90-265Vac
Rated Charge Current(max)	32A	40A	48A
Operating Frequency	50/60Hz	50/60Hz	50/60Hz
Shell Protection Grade	IP65	IP65	IP65
Communications & UI
HCI	Indicator + OLED 1.3” display	Indicator + OLED 1.3” display	Indicator + OLED 1.3” display
Communication Method	WiFi 2.4GHz/ Bluetooth	WiFi 2.4GHz/ Bluetooth	WiFi 2.4GHz/ Bluetooth
General Specifications
Operating Temperature	-40℃ ~+80℃	-40℃ ~+80℃	-40℃ ~+80℃
Storage Temperature	-40℃ ~+80℃	-40℃ ~+80℃	-40℃ ~+80℃
Product Length	7.6 m	7.6 m	7.6 m
Body Size	2229270 mm	2229270 mm	2229270 mm
Product Weight	3.24 kg (N.W.) 3.96 kg (G.W.)	3.68 kg (N.W.) 4.4 kg (G.W.)	4.1 kg (N.W.) 4.8 kg (G.W.)
Package Size	411336120 mm	411336120 mm	411336120 mm
Protections	leakage protection, over temperature protection, surge protection, Over-current protection, automatic power-oﬀ, undervoltage protection, Over-voltage protection, CP failure
