● Compact & Portable: Easy to carry and ideal for travel or daily use.
● Adjustable Current: Set charging current to suit your needs.
● Certified & Reliable: Meets European safety and quality standards.
● IP65 Rated: Water and dust resistant for indoor and outdoor use.
● Temperature Monitoring: Real-time heat detection for safe charging.
● Fast & Efficient: High-efficiency power delivery for reduced charge time.
● Multi-layer Protection: Built-in safeguards against over-voltage, overheating, and more.
Model |
EVSEP-3-EU1 |
EVSEP-7-EU1 |
EVSEP-11-EU1 |
EVSEP-22-EU1 |
Electrical Specifications | ||||
Operating Voltage |
230Vac±15% |
230Vac±15% |
400Vac±15% |
400Vac±15% |
Rated Input/
Output Voltage |
230Vac |
230Vac |
400Vac |
400Vac |
Rated Charge
Current(max) |
16A |
32A |
16A |
32A |
Operating Frequency |
50/60Hz |
|||
Enclosure Protection
Class |
IP65 |
|||
Communications & UI | ||||
HCI |
Touch key |
|||
Communication
Method |
Bluetooth / Wi-Fi( optional) |
|||
General Specifications | ||||
Operating
Temperature |
-25℃~+50℃ |
|||
Storage Temperature |
-40℃~+80℃ |
|||
Body Size |
221*98*58 mm |
|||
Package Size |
400*360*95 mm |
|||
Protections |
Leakage protection, Over temperature protection, Overload Protection, Over-current protection, Undervoltage protection, Over-voltage protection, Lightning Protection, RelayBonding Protection |
